Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option
233), and GPS Receiver (Option 307))
How to Set Up Mapping Settings
A KDAT file is the file FieldFox uses to recall an indoor mapping/data
logging session ("Recall Indoor Log File"). It's an archive file that contains
information about the original image file, the location of the recorded data
on the image and the actual recorded data. KDAT files can only be opened
with FieldFox itself. KDAT files cannot be opened via Data Link.
An auxiliary CSV data file is generated automatically, each time a KDAT file
is saved during an indoor mapping session. The CSV contains the recorded
data, without the image, location of the recorded data, etcetera.
3. Press
Keysight N9915-90020 User's Guide
Data Selection
Save
Back
Record Save/Recall
logging filenames and file folder locations
—
Save Log File
or
—
Recall Log File
(if you have previously stored data)
Opens a softkey menu to set the active data
channel, sort type, and sort order.
Channel 1
——
channel being recorded.
Available channels will vary
within each mode.
Sort Power Freq
——
type of measurement displayed
(Power or Frequency).
Sort Order Up Down
——
sort order to ascending (Up)
greater power/frequencies
displayed first or descending
(Down) lowest power or
frequency values displayed first.
Opens a softkey menu to enable you to save your
map (.kdat) or your image (.png).
Save Map
——
log file" where you can name
and save your map file (kDAT).
Softkey is only visible when data
is recorded on a *.png file using
Labels & Icons feature and the
Record softkey.
Save Image (PNG)
——
current displayed map to a *.png
file (default filename is
"MapImageFile"). This softkey is
on active when View Maps = O.
Returns to previous softkey menu.
Opens a softkey menu to manage your data
- Sets the data
- Sets the
- Sets the
- Opens "Save the
- Saves the
509
