Oracle Fujitsu SPARC M12-1 Service Manual page 68

(3): Device path name and logical path name of the disk mounted in HDD#2
# diskinfo
D:devchassis-path
------------------------------------------
:
/dev/chassis/SYS/HDD00/disk
/dev/chassis/SYS/HDD01/disk
/dev/chassis/SYS/HDD02/disk
/dev/chassis/SYS/HDD03/disk
/dev/chassis/SYS/HDD04/disk
/dev/chassis/SYS/HDD05/disk
/dev/chassis/SYS/HDD06/disk
/dev/chassis/SYS/HDD07/disk
#
Using the diskinfo command (Oracle Solaris 10)
Execute the diskinfo command to check the HDD/SSD slots.
1.
(1) to (3) in the following example represent:
(1): Device path name and logical path name of the disk mounted in HDD#0
(2): Device path name and logical path name of the disk mounted in HDD#1
(3): Device path name and logical path name of the disk mounted in HDD#2
# diskinfo -ap
Enclosure path:
Chassis Serial Number:
Chassis Model:
Enclosure path:
Chassis Serial Number:
Chassis Model:
Label Disk name
---------- ----------------------
HDD_0 c0t50000393B81B3A36d0
Physical path
--------------------------------
0: /pci@8100/pci@4/pci@0/pci@0/scsi@0/iport@f/disk@w50000393b81b3a36,0
HDD_1 c0t500000E01FB332A2d0
Physical path
--------------------------------
0: /pci@8100/pci@4/pci@0/pci@0/scsi@0/iport@f/disk@w500000e01fb332a2,0
HDD_2 c0t50000393B81B4D7Ad0
Physical path
--------------------------------
0: /pci@8100/pci@4/pci@0/pci@0/scsi@0/iport@f/disk@w50000393b81b4d7a,0
54 Fujitsu SPARC M12-1 Service Manual • January 2023
TZ01232002-physical-hba-0
TZ01232002-physical-hba-0
ORCL,SPARC64-X
/dev/es/ses0
500000e0e04901bf
FUJITSU-NBBEXP
Vendor
-------- ---------------- ----
TOSHIBA
TOSHIBA
TOSHIBA
c:occupant-compdev
---------------------
c0t50000393B81B3A36d0 <-- (1)
c0t500000E01FB332A2d0 <-- (2)
c0t50000393B81B4D7Ad0 <-- (3)
Product Vers
MBF2600RC 3706 <-- (1)
MBF2600RC 3706 <-- (2)
MBF2600RC 3706 <-- (3)
