13.4
Installing the Cable Kit
This section describes the procedure for connecting the cable kit.
13.4.1
Installing the Cable Kit
Lift the PSUBP, and connect the four cables (A in
1.
Figure 13-7 PSUBP Cables
2.
Install the PSUBP.
Confirm that the two fixing pins are inserted into the PSUBP, and then slide
3.
the PSUBP toward the front of the SPARC M12-1.
4.
Tighten the one screw of the PSUBP.
168
Fujitsu SPARC M12-1 Service Manual • January 2023
Figure
13-7) to the PSUBP.
A
