Figure 2-4 Memory Installation Locations and Units
Table 2-2 Memory Installation Configurations
Memory Module
Count
4
8
16
2.2.2

Checking Memory Information

Check the type and size of memory by using the showhardconf command of the
XSCF firmware.
Log in to the XSCF shell.
1.
Execute the showhardconf command to check the memory information.
2.
The capacity and rank of memory are displayed.
XSCF> showhardconf
SPARC M12-1;
+ Serial:TZ41702014; Operator_Panel_Switch:Service;
+ System_Power:On; System_Phase:Cabinet Power On;
Partition#0 PPAR_Status:Running;
MBU Status:Normal; Ver:3025h; Serial:TZ1701D01B
+ FRU-Part-Number:CA08208-D001 A0
+ Power_Supply_System:Dual;
+ Memory_Size:64 GB; Type: C ;
Mirroring
Installed Memory
a in Figure 2-4 -
a in Figure 2-4 b in
a in Figure 2-4 b in
b
a
CPU#0
c
d
Front
-
Figure 2-4 -
Figure 2-4 c in Figure 2-4
;
/9999999
Chapter 2 Understanding the System Components
Mirroring
-
-
d in Figure 2-4
;
