Table 7-1 Maintenance Workflow (continued)
Item
4-c System-stopped removal
*1 The configuration of the system requiring maintenance and the FRU to be replaced may affect system
operation, such as in maintenance time and in stopping the logical domains. Consult with the system administrator
to decide the maintenance type to be used.
Table 7-2 Maintenance Types for FRUs
FRU
PCIe card
HDD/SSD
HDDBP
PSU
PSUBP
Cable kit
OPNL
FANU
MBU
Memory
*1 Active/Hot maintenance and system-stopped (inactive)/hot maintenance can be performed on PCIe cards
mounted in the PCI expansion unit. For details, see "3.3 Types of Maintenance for the PCIe Card" in the PCI
Expansion Unit for Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Service Manual.
*2 Supported only for internal storage other than the boot device. However, if the boot device has a redundant
configuration (RAID configuration), active/hot maintenance can be performed on the HDD/SSD that is the boot
device.
*3 If the XSCF startup mode is high-speed mode, hardware cannot be replaced using the replacefru command.
Perform system-stopped (inactive)/cold maintenance.
94 Fujitsu SPARC M12-1 Service Manual • January 2023
Procedure
Active/Hot
Maintenance
- (*1)
OK (*2)
-
OK (*3)
-
-
-
OK
-
-
Reference
"7.4.2 System-Stopped
-: Maintenance cannot be performed.
System-Stopped System-Stopped
(Inactive)/Hot (Inactive)/Cold
Maintenance Maintenance
- (*1) OK
OK OK
- OK
OK (*3) OK
- OK
- OK
- OK
OK OK
- OK
- OK
Removal"
Reference
Chapter 8
Chapter 9
Chapter 10
Chapter 11
Chapter 12
Chapter 13
Chapter 14
Chapter 15
Chapter 16
Chapter 16
