Remove the two cables connecting the OPNL to the MBU.
3.
Note - Record the positions of the cables before removing them, to ensure that they are
reinstalled correctly.
Figure 10-3 OPNL Cables
4.
Loosen the two screws of the HDDBP.
Figure 10-4 HDDBP Screws
140
Fujitsu SPARC M12-1 Service Manual • January 2023
