10.4

Installing the HDDBP

10.4.1
Installing the HDDBP
This section describes the procedure for installing the HDDBP.
Install the HDDBP by aligning the notches on both sides.
1.
Figure 10-6 　 　 HDDBP Notches
2.
Align the HDDBP with hooks on the chassis (three places) and push the
HDDBP into place.
Figure 10-7 　 　 Hooks on the Chassis
142
Fujitsu SPARC M12-1 Service Manual • January 2023
