Figure 15-1 Locations of the FANUs
Location No.
1
2
3
4
5
6
7
15.3

Removing a FANU

This section describes the procedure for removing a FANU.
Enable removal of the FANU before attempting to remove it. For details, see
"Chapter 7 Maintenance
Caution - Before you handle any components, wear a wrist strap to ground any static
electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be damaged. For details, see
178 Fujitsu SPARC M12-1 Service Manual • January 2023
(1) (2) (3) (4) (5) (6)
Component
Fan unit (FAN#0)
Fan unit (FAN#1)
Fan unit (FAN#2)
Fan unit (FAN#3)
Fan unit (FAN#4)
Fan unit (FAN#5)
Fan unit (FAN#6)
Flow."
(7)
"1.4 Precautions
