Figure 10-1 Location of the HDDBP
Location No.
1
10.3

Removing the HDDBP

This section describes the procedure for removing the HDDBP.
Enable removal of the HDDBP before attempting to remove it. For details, see
"Chapter 7 Maintenance
Caution - Before you handle any components, wear a wrist strap to ground any static
electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be damaged. For details, see
on Static
10.3.1

Accessing the HDDBP

1. Pull the SPARC M12-1 out of the rack.
For details, see
138 Fujitsu SPARC M12-1 Service Manual • January 2023
(1)
Component
HDD backplane (HDDBP)
Flow."
Electricity."
"5.8.3 Pulling the SPARC M12-1 Out From the
"1.4 Precautions
Rack."
