11.3.2

Removing a PSU

While pushing the lever (A in
1.
grab the handle (B in
Figure 11-3 Removing a PSU
2. Support the PSU with one hand from below, and carefully pull it out of the
slot.
Note - Place the removed PSU on a grounded ESD mat to ground any static electricity.
11.4

Installing a PSU

11.4.1 Installing a PSU
This section describes the procedure for installing a PSU.
Support the PSU from below with one hand, and insert it carefully into its slot.
1.
150 Fujitsu SPARC M12-1 Service Manual • January 2023
Figure
B
A
Figure 11-3) of the PSU requiring maintenance,
11-3) to pull the PSU out.
