Figure 8-1 Locations of the PCIe Cards
Location No.
1
2
3
8.3

Removing a PCIe Card

This section describes the procedure for removing a PCIe card. Use the same
procedure for reduction too.
For expansion, remove the PCIe card filler instead of the PCIe card itself.
Enable removal of the PCIe card before attempting to remove it. For details, see
"Chapter 7 Maintenance
Caution - Before you handle any components, wear a wrist strap to ground any static
electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be damaged. For details, see
on Static
124 Fujitsu SPARC M12-1 Service Manual • January 2023
(1)
(2)
Component
PCIe card (PCI#0)
PCIe card (PCI#1)
PCIe card (PCI#2)
Flow."
Electricity."
(3)
"1.4 Precautions
