5.8.3

Pulling the SPARC M12-1 Out From the Rack

To perform maintenance on an internal FRU in the SPARC M12-1, pull the SPARC
M12-1 out of the rack.
Caution - If the rack is supplied with a quakeresistant options kit, install it. The
quakeresistant options kit will prevent the rack from falling over when you pull the
SPARC M12-1 out along the slide rails when performing maintenance.
1. Pull the levers on the right and left sides of the SPARC M12-1 outward to
release the lock.
Figure 5-3 Levers on the Right and Left Sides
While pulling the levers outward, pull the SPARC M12-1 out as far as possible.
2.
Once the SPARC M12-1 has been completely pulled out, it is automatically
locked into the prescribed position.
Figure 5-4 Pulling Out the SPARC M12-1
