Install the PSUBP cover by tilting it, inserting the latch (A in
1.
sliding the cover to the rear.
Note - Confirm that the latch of the PSUBP cover is secured.
Figure 6-2 Installing the PSUBP Cover
2. Attach the air duct vertically.
Fit the air duct guides (four locations) (A in
MBU, and secure them with the pins (two locations) (B in
Figure 6-3 Installing the Air Duct
Chapter 6 Understanding the Preparations for Restoring the System
Figure
A
Figure 6-3) into the notches on the
Figure 6-3).
B
A
6-2), and
