Active/Hot replacement (for an HDD/SSD not in a RAID configuration)
Active/Hot replacement can be performed on an HDD/SSD. If the HDD/SSD is not in
a RAID configuration, perform the following procedure to replace it.
Figure 7-3 Active/Hot Replacement Flow (for an HDD/SSD Not in a RAID
1. Opening the rack door
2. Checking the operating condition of the
system and the I/O device usage status
3. Releasing a faulty HDD/SSD from the system
4. Replacing the faulty HDD/SSD
5. Incorporating the replacement HDD/SSD
6. Confirming that there is no problem with the
replacement FRU
7. Closing the rack door
Table 7-5 Active/Hot Replacement Work Procedure (for an HDD/SSD Not in a RAID Configuration)
Item Work Procedure
1 Opening the rack door
2 Checking the operating condition of the
system and the I/O device usage status
3 Releasing the faulty HDD/SSD from the
system
4 Replacing the faulty HDD/SSD
5 Incorporating the replacement HDD/SSD
6 Confirming that there is no problem with
the replacement FRU
7 Closing the rack door
98 Fujitsu SPARC M12-1 Service Manual • January 2023
Configuration)
Maintenance complete
Reference
"5.3 Checking the Operating Condition and Resource
Usage Status"
"5.4 Enabling the Removal of a
"Chapter 9 Maintaining Internal
"6.6 Incorporating the
"6.7 Checking the FRU Status After
HDD/SSD"
Storage"
HDD/SSD"
Maintenance"
