Components that can be accessed from the front
Figure 2-1 Locations of Components That Can be Accessed From the Front
Location No.
1
*1 Represents both a hard disk drive (HDD) and solid state drive (SSD) unless otherwise noted.
Letters in parentheses are an abbreviation for the component. Below, each
component is represented by its abbreviation unless otherwise noted.
Components that can be accessed from the rear
Figure 2-2 Locations of Components That Can be Accessed From the Rear
Location No.
1
10 Fujitsu SPARC M12-1 Service Manual • January 2023
Component
Internal storage (HDD/SSD) (*1)
(1)
Component
Power supply unit (PSU)
(1)
