How to use a wrist strap
Wear a wrist strap in such a way that the inner metal surface (A in
wrist strap band is in contact with your skin. Connect the clip (B in
directly to the chassis.
Caution - Do not connect the wrist strap clip to the ESD mat. By connecting the wrist
strap clip to the chassis, the operator and components have the same electrical
potential, thus eliminating the danger of static damage.
Figure 1-3 Wrist Strap Connection Destinations
1.5

Other Precautions

Caution - Observe the following precautions to ensure the safety of the system.
The printed boards in the SPARC M12-1 can be easily damaged by static
■
electricity. To prevent damage to the printed boards, wear a wrist strap and
ground it to the SPARC M12-1 prior to starting maintenance.
A
Chapter 1 Before Starting Maintenance Work
Figure 1-3) of the
Figure 1-3)
B
