Installing Memory; Restoring The Server - Oracle Fujitsu SPARC M12-1 Service Manual

Note - Reinstall the FANUs at their original locations by referring to the record that you
made before the start of maintenance.
16.6.2

Installing Memory

This section describes the procedure for installing memory.
To expand memory, see
install memory.
1. Put the memory in place.
To install memory in a memory slot, confirm that the latches on both sides of the
slot are open. Align the key notch with the slot key of the memory, and put the
memory into the memory slot.
Figure 16-16 Installing Memory
Note - Reinstall the memory at their original locations by referring to the record that you
made before the start of maintenance.
2. Secure the memory.
Evenly push both ends of the memory until the memory slot latch closes.
Figure 16-17 Securing the Memory
Note - Confirm that the memory slot latch has returned to its original position.
16.6.3

Restoring the Server

Install the air duct and the PSUBP cover.
1.
For details, see
"2.2 Checking the Memory Configuration
"6.1.2 Installing the Air Duct and PSUBP
Chapter 16 Maintaining the Motherboard Unit/Memory
Rules," and
Cover."
199
