15.4

Installing a FANU

This section describes the procedure for installing a FANU.
15.4.1 Installing a FANU
Install a FANU straight down into its slot.
1.
Caution - Do not forcibly push the FANU into its slot. Using excessive force may
damage the FANU and server.
2. Push the FANU firmly, with the connector on the back of the FANU aligned
with the connector on the MBU.
Note - Make sure that the FANU is firmly inserted and fixed.
15.4.2

Restoring the FANUs and Server

Close the fan cover.
1.
See
Put the SPARC M12-1 into the rack.
2.
See
The FRU installation work is completed. See
continue maintenance work.
180 Fujitsu SPARC M12-1 Service Manual • January 2023
"6.1.4 Closing the Fan
"6.1.5 Putting the SPARC M12-1 Into the
Cover."
Rack."
"Chapter 7 Maintenance Flow" to
