Slide the PSUBP toward the rear of the SPARC M12-1 to release it from two
5.
fixing pins (A in Figure
Figure 13-5 Fixing Pins of the PSUBP
6. Lift the PSUBP, and disconnect the four cables (A in
to the PSUBP.
Note - Record the positions of the cables before removing them, to ensure that they are
reinstalled correctly.
Note - Place the removed PSUBP on a grounded ESD mat to ground any static electricity.
Figure 13-6 PSUBP Cables
13-5).
Chapter 13 Maintaining the Cable Kit
A
Figure 13-6) connected
A
