Table 7-12 System-Stopped/Cold Addition Work Procedure
Item Work Procedure
1 Opening the rack door
2 Switching the mode switch on the
operation panel to Service mode
3 Checking the operating condition
of the system and the I/O device
usage status
4 Stopping the system
5 Removing the power cords
6 Adding the target FRU
7 Installing the power cords
8 Performing a diagnosis test
9 Confirming that there is no
problem with the added FRU
10 Returning the mode switch on the
operation panel to Locked mode
11 Starting the system
12 Closing the rack door
7.4

FRU Removal Workflow

This section describes the removal workflow for the following FRUs of the SPARC
M12-1:
- PCIe card
- Memory
- HDD/SSD
7.4.1

Active Removal

This section describes the workflow for active/hot FRU removal. References to
detailed descriptions are written in the workflow. See any of them as required.
Active removal on the SPARC M12-1 has the following patterns:
Active/Hot removal (HDD/SSD)
■
Reference
"5.2 Switching the Mode Switch to Service
"5.3 Checking the Operating Condition and Resource Usage
"5.5 Stopping the Entire
"5.8.1 Removing the Power
When adding a PCIe card:
"Chapter 8 Maintaining the PCI Express
When adding an HDD/SSD:
"Chapter 9 Maintaining Internal
"6.1.6 Installing the Power
"6.4 Diagnosing a Replacement
"6.7 Checking the FRU Status After
"6.8 Returning the Mode Switch to Locked
"6.9 Starting the System"
Mode"
System"
Cords"
Cards"
Storage"
Cords"
FRU"
Maintenance"
Mode"
Chapter 7 Maintenance Flow
Status"
