D.1.1

Wire Connection Chart for Serial Cables

Figure D-1 Wire Connection Chart for Serial Cables
D.2

USB Port

Table
Table D-2 USB 2.0 Port (Front)
Pin Arrangement
1 2 3 4
Table D-3 USB 3.0 Port (Rear)
Pin Arrangement
9
1 2 3 4
222 Fujitsu SPARC M12-1 Service Manual • January 2023
D-2, Table D-3, and Table D-4
Pin
Number
1
2
3
4
Pin
Number
1
8 7 6 5
2
3
list the specifications of the USB port.
Signal Input/Output
Name
VBUS Output
-DATA Input/
Output
+DATA Input/
Output
GND ---
Signal Input/Output
Name
VBUS Output
-DATA Input/
Output
+DATA Input/
Output
Description
Power supply
Data
Data
Ground
Description
Power supply
Data
Data
