Figure 2-6     Location of the Operation Panel
Figure 2-7     Appearance of the Operation Panel
(1)
Location No.
1
2
3
4
5
2.3.1

Display Function of the Operation Panel

The operation panel has three LED indicators as a display function. The LED
indicators show the following. For details, see
General system status
System error warning
System error location
(2)
(3)
LED/Switch
POWER LED
XSCF STANDBY LED
CHECK LED
Mode switch
Power switch
(4)
"2.4.1 Operation Panel
Chapter 2 Understanding the System Components
(5)
LEDs."
