(Current) :confirm_service_manual
(Next) :confirm_service_manual
-----------------------------------------------------------------------------
Index :1
config_name :factory-default
domains :1
date_created:-
-----------------------------------------------------------------------------
Index :2
config_name :config_develop_env
domains :3
date_created:'2016-05-24 19:40:55'
XSCF>
*1 Currently running logical domain configuration
*2 factory-default configuration
Confirming the firmware configuration
Check the XCP firmware version by using the version command, which is an XSCF
shell command.
1. Log in to the XSCF shell.
Execute the version command to confirm the firmware version information.
2.
In the following example, "-c xcp" is entered to confirm the overall XCP version.
XSCF> version -c xcp
BB#00-XSCF#0 (Master)
XCP0 (Reserve): 3060
XCP1 (Current): 3060
*1 XCP firmware version installed at Reserve for the SPARC M12-1
*2 XCP firmware version running on the SPARC M12-1
Check the firmware version of the PCI expansion unit by using the ioxadm
command, which is an XSCF shell command.
1. Log in to the XSCF shell.
2. Identify the mounting locations of the PCI expansion unit and link card.
XSCF> ioxadm list
PCIBOX
PCIBOX#6002
*1 Mounting locations of the PCI expansion unit and link card
Execute the ioxadm command to check the firmware version information for
3.
the PCI expansion unit and link card.
34 Fujitsu SPARC M12-1 Service Manual • January 2023
(*1)
(*2)
(*1)
(*2)
Link
BB#00-PCI#00 (*1)
