Connect the three cables that connect the PSUBP to the MBU.
7.
Note - Connect the cables in their original positions by referring to the record that you made
before the start of maintenance.
Note - Make sure that each cable is firmly inserted.
Figure 12-9 MBU Cables
12.5.2

Restoring the Server

Install the air duct and the PSUBP cover.
1.
For details, see
2. Install the upper cover.
For details, see
3. Close the fan cover.
For details, see
Install all the PSUs.
4.
For details, see
The FRU installation work is completed. See
continue maintenance work.
"6.1.2 Installing the Air Duct and PSUBP
"6.1.3 Installing the Upper
"6.1.4 Closing the Fan
"11.4 Installing a PSU."
Chapter 12 Maintaining the PSU Backplane
Cover."
Cover."
Cover."
"Chapter 7 Maintenance Flow" to
