Oracle Fujitsu SPARC M12-1 Service Manual page 31

Location No.
1
2
The mode switch sets the operation mode for the system. The Locked and Service
operation modes can be switched by sliding the mode switch.
Table 2-3
Table 2-3 Functions of the Mode Switch
Icon
Use the power switch to start or stop the system. The system starts/stops differently
depending on how the power switch is pressed.
Table 2-4
switch is pressed.
Table 2-4 Functions of the Power Switch
Icon Operation
Brief press
(For 1 second or
more and less than 4
seconds)
Long press
(For 4 seconds or
more)
Switch
Mode switch
Power switch
describes the difference between the modes.
Name Description
Locked mode Mode used for normal operation
- The power switch can be used to start the system but not to
stop it.
Service mode Mode used for maintenance
- The power switch cannot be used to start the system but can be
used to stop it.
- Place the system in Service mode to perform maintenance
work with the system stopped.
describes how system starts/stops vary depending on how the power
Description
If the system has been
started in Service mode:
If the system is stopped in
Service mode:
If the system has been
started in Locked mode:
If the system is stopped in
Locked mode:
If the system has been
started in Service mode:
If the system startup
process is in progress in
Service mode:
If the system stop process
is in progress in Service
mode:
Operation is ignored.
Operation is ignored.
Operation is ignored.
Starts the system.
If a wait time for air conditioning facilities or a
warmup time is set on the XSCF, the process of
waiting for the facilities to power on and for the
warmup to complete is omitted at this time.
Perform the system shutdown process to stop the
system.
Cancels the system startup process and stops the
system.
Continues the system stop process.
Chapter 2 Understanding the System Components 17
