Active/Hot replacement (for an HDD/SSD in a RAID configuration)
Active/Hot replacement can be performed on an HDD/SSD. If the HDD/SSD is in a
RAID configuration, perform the following procedure to replace it.
Figure 7-2 Active/Hot Replacement Flow (for an HDD/SSD in a RAID
1. Opening the rack door
2. Checking the HDD/SSD status
3. Identifying a faulty HDD/SSD
4. Replacing the HDD/SSD
5. Confirming that there is no problem with the
replacement FRU
6. Closing the rack door
Table 7-4 Active/Hot Replacement Work Procedure (for an HDD/SSD in a RAID Configuration)
Item Work Procedure
1 Opening the rack door
2 Checking the HDD/SSD status
3 Identifying a faulty HDD/SSD
4 Replacing the faulty HDD/SSD
5 Confirming that there is no problem with
the replacement FRU
6 Closing the rack door
Configuration)
Maintenance complete
Reference
"14.2.8 Checking the Status of a Hardware RAID Volume
and a Disk Drive" in the Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 System Operation and Administration Guide
"14.2.9 Checking for a Failed Disk Drive" in the Fujitsu
SPARC M12 and Fujitsu M10/SPARC M10 System Operation
and Administration Guide
"14.2.10 Replacing a Failed Disk Drive" in the Fujitsu
SPARC M12 and Fujitsu M10/SPARC M10 System Operation
and Administration Guide
"Chapter 9 Maintaining Internal
"6.7 Checking the FRU Status After
Storage"
Maintenance"
