Install an SD card.
3.
Insert the SD card that contains the XSCF firmware to be used into the socket of
the MBU. Secure the SD card by pushing it until its latch locks into place.
Figure 16-10 Installing an SD Card
Caution - Be careful not to damage the SD card connector by pushing in the SD card
too hard.
4. Install the SD card protection cover.
Install the protection cover on the MBU, and secure it with the screw (A in
Figure
Figure 16-11 Installing the SD Card Protection Cover
Note - Return the SD card supplied with the new MBU by installing it in the removed MBU.
194 Fujitsu SPARC M12-1 Service Manual • January 2023
16-11).
