Figure 2-12 LED Locations of the XSCF-LAN Ports
Table 2-10 XSCF-LAN Port LEDs and Their States
Location
No.
1
2
Figure 2-13 LED Locations of the On-Board LAN Ports
22 Fujitsu SPARC M12-1 Service Manual • January 2023
Name Color
LINK SPEED Amber
Green
-
ACT Green
-
(1) (2) (1) (2) (1) (2) (1)
(1) (1)
State Description
On Indicates that the communication
speed is 1 Gbps.
On Indicates that the communication
speed is 100 Mbps.
Off Indicates that the communication
speed is 10 Mbps.
Blinking Indicates that communication is
being performed.
Off Indicates that communication is not
being performed.
(2)
(2) (2)
