If you unlocked and released the cable management arm, restore it to its
3.
original state.
Note - Confirm that the cable management arm is locked with its tab (A in
Figure 6-11 Cable Management Arm Tab
A
6.2 Incorporating a FRU Into the System
With the replacefru Command
This section describes the procedure for incorporating a Field Replaceable Unit (FRU)
into the system after maintenance. To do this, resume the replacefru command,
which is running, to incorporate the FRU into the system. The following FRUs can be
maintained.
PSU
■
FANU
■
1. After performing maintenance on the FRU, return to the operation of the XSCF
firmware replacefru command, and enter "f".
Please execute the following steps:
1) Confirm the Check LED is blinking.
2) Remove FAN#6.
3) Execute either the following:
3-1) After installing the exchanged device, please select 'finish'.
3-2) If you want to suspend the maintenance without exchanging device,
80 Fujitsu SPARC M12-1 Service Manual • January 2023
Figure 6-11).
