Table 2-6 System Operation Status Indicated by LEDs
Icon Name Color
POWER Green
-
XSCF Green
STANDBY
-
CHECK Amber
-
Table 2-7 System Status Indicated by a Combination of LEDs
LED State
POWER XSCF
STANDBY
Off Off
Off Off
Off Blinking
Off On
On On
On On
Blinking On
State Description
On The system is running.
Blinking The system is being stopped.
Off The system is stopped.
On The XSCF is functioning normally.
Blinking The XSCF is being initialized.
Off The XSCF is stopped.
On Hardware has detected an error.
Blinking The SPARC M12-1 specified at execution of
the XSCF command instructing the blinking.
This (locator) is used to identify the location
of the SPARC M12-1 requiring maintenance.
Off Normal state, or the power is disconnected or
otherwise not being supplied.
Description
CHECK
Off The power is disconnected.
On The XSCF has detected an error before system
start or after system stop.
Off The XSCF is being initialized.
Off The XSCF is in the standby state.
Or the system is waiting for power-on of the air
conditioning facilities (in the data center).
Off Warm-up standby processing is in progress. After
the end of this processing, the system starts up.
Or the system startup processing is in progress.
Or the system is in operation.
On Although the system is operating normally, an
error has been detected.
Off System stop processing is in progress. After the
end of processing, the fan unit stops.
