Figure 14-1 Location of the OPNL
Location No.
1
14.3

Removing the OPNL

This section describes the procedure for removing the OPNL.
Enable removal of the OPNL before attempting to remove it. For details, see
7 Maintenance
Caution - Before you handle any components, wear a wrist strap to ground any static
electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be damaged. For details, see
on Static
14.3.1

Accessing the OPNL

1. Pull the SPARC M12-1 out of the rack.
For details, see
Open the fan cover.
2.
For details, see
Remove the upper cover.
3.
For details, see
172 Fujitsu SPARC M12-1 Service Manual • January 2023
Component
Operation panel (OPNL)
Flow."
Electricity."
"5.8.3 Pulling the SPARC M12-1 Out From the
"5.8.4 Opening the Fan
"5.8.5 Removing the Upper
(1)
"1.4 Precautions
Cover."
Cover."
"Chapter
Rack."
