Remove all the HDDs/SSDs and internal storage filler units mounted in the
2.
chassis.
For details, see
Note - Record the mounting locations of the HDDs/SSDs before removing them, to ensure
that they are reinstalled correctly.
3. Open the fan cover.
For details, see
4. Remove the upper cover.
For details, see
10.3.2

Removing the HDDBP

1. Remove the three cables connected to the HDDBP.
Note - Record the positions of the cables before removing them, to ensure that they are
reinstalled correctly.
Figure 10-2 HDDBP Cables
2. Release the cable guide lock.
For details, see
If the cable guide does not have a lock, proceed to step 3.
"9.3 Removing an HDD/SSD."
"5.8.4 Opening the Fan
"5.8.5 Removing the Upper
"5.8.7 Releasing the Cable Guide
Chapter 10 Maintaining the HDD Backplane
Cover."
Cover."
Lock."
139
