Name
interrupt_map48_0
interrupt_map49_0
interrupt_map50_0
interrupt_map51_0
interrupt_map52_0
interrupt_map53_0
interrupt_map54_0
interrupt_map55_0
interrupt_map56_0
interrupt_map57_0
interrupt_map58_0
interrupt_map59_0
interrupt_map60_0
interrupt_map61_0
interrupt_map62_0
interrupt_map63_0
int_mapper_1
perf_cnt_cfg
perf_cnt_0
perf_cnt_1
perf_cnt_2
perf_cnt_3
bus_err_status
bus_err_status_debug
bus_err_data_0
bus_err_data_1
bus_err_data_2
bus_err_data_3
bus_l2_errors
bus_mem_io_errors
Page 460 Section 16: Reference
Table 311: Internal Register Addresses by Function
Table/
Address
Page
18/47
00_1002_0380
18/47
00_1002_0388
18/47
00_1002_0390
18/47
00_1002_0398
18/47
00_1002_03a0
18/47
00_1002_03a8
18/47
00_1002_03b0
18/47
00_1002_03b8
18/47
00_1002_03c0
18/47
00_1002_03c8
18/47
00_1002_03d0
18/47
00_1002_03d8
18/47
00_1002_03e0
18/47
00_1002_03e8
18/47
00_1002_03f0
18/47
00_1002_03f8
00_1002_2000
SCD: Performance Counters
31/61
00_1002_04c0
32/62
00_1002_04d0
32/62
00_1002_04d8
32/62
00_1002_04e0
32/62
00_1002_04e8
SCD: Bus Watcher
35/65
00_1002_0880
36/65
00_1002_08D0
37/65
00_1002_08a0
37/65
00_1002_08a8
37/65
00_1002_08b0
37/65
00_1002_08b8
38/66
00_1002_08c0
39/66
00_1002_08c8
B r oadco m C orp or ati on
(Cont.)
Description
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
Source to IRQ map register.
2000-23f8 Registers for CPU 1 interrupt mapper (+2000
from CPU 0).
Performance counter control.
Performance counter.
Performance counter.
Performance counter.
Performance counter.
Bus error status (Read Only).
Bus error status (Read Only).
Data or address/control information latched on bus error
(Read Only).
Data or address/control information latched on bus error
(Read Only).
Data or address/control information latched on bus error
(Read Only).
Data or address/control information latched on bus error
(Read Only).
Count of L2 ECC errors (4 8-bit counters).
Count of memory ECC errors and I/O errors (3 8-bit
counters).
