BCM1250/BCM1125/BCM1125H
Start
Address
Offset
in bytes
Aligned
to 32
byte block
Page 150 Section 7: DMA
size (in cache blocks)
Packet
L1 (in bytes)
Start
Address
Offset
in bytes
Aligned
to 32
byte block
Start
Address
Aligned
to 32
byte block

Figure 25: Packet Spanning Three Buffers

B r oadco m C orp or ati on
Aligned
to 32
byte block
size (in cache blocks)
Packet
L2 (in bytes)
size (in cache blocks)
Offset
Packet
in bytes
L3 (in bytes)
Length = L1 + L2 + L3 in bytes
User Manual
Aligned
to 32
byte block
Unused
Aligned
to 32
byte block
Document 1250_1125-UM100CB-R
10/21/02
