PC BOARD MOUNTING FOOTPRINT
82X Ø.040 ±.003 THRU
AFTER PLATING
2X Ø.213 +.003/-.000 THRU
Notes
1. J1 signals must be connected for current-sharing.
2. To determine copper width and thickness for J1 signals refer to specification IPC-2221.
(Association Connecting Electronic Industries, http://www.ipc.org)
3. Standoffs should be connected to etches on pc board that connect to frame ground for maximum noise
suppression and immunity.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Top View
Dimensions in inches
0.500
2
AFTER PLATING
Accelnet R22 Mounting Hardware:
Qty Description
1 Socket Strip
1 Socket Strip
2 Standoff 6-32 X 3/8"
BRUSHLESS/BRUSH MOTORS
1.880
0.990
1
0.100
(TYP)
0.100
(TYP)
0.100
(TYP)
Mfgr Part Number
Samtec SSW-116-01-S-D J2
Samtec SSW-125-01-S-D J1
PEM
Tel: 781-828-8090
R22
RUGGEDIZED DIGITAL
SERVO DRIVE FOR
.000
J1 Signal Grouping
for current-sharing
0.490
2 1
.000
2.990
Remarks
KFE-632-12-ET
Fax: 781-828-6547
