Copley Controls Xenus R10 Manual page 53

MAXIMUM AMBIENT TEMPERATURE VS. OUTPUT CURRENT, MOUNTING, AND COOLING
The graphs below show the maximum ambient operating temperature for the drive vs. output current for the Xenus R11 models at 120 and 240 Vac mains
voltages and under different mounting and cooling conditions.
Model: R11-230-02, R11-230-06, R11-230-10
Mains: 120 Vac
70
60
50
40
30
20
0
Continuous Output Current (Adc)
Model: R11-230-02, R11-230-06, R11-230-10
Mains: 240 Vac
70
60
50
40
30
20
0
Continuous Output Current (Adc)
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Xenus R11
3
2
1
1 2 3 4
4
3
2
1
1 2 3 4
BRUSHLESS/BRUSH MOTORS
5
4
1 = No HS or fan, convection
2 = With HS, convection
3 = No HS, with fan
4 = With HS, with fan
5 = Infinite heatsink
5
5
1 = No HS or fan, convection
2 = With HS, convection
3 = No HS, with fan
4 = With HS, with fan
5 = Infinite heatsink
5
Tel: 781-828-8090
R11
RUGGEDIZED DIGITAL
SERVO DRIVE FOR
Fax: 781-828-6547
Page 23 of 24
RoHS
