PC BoARD MoUnTInG FooTPRInT
Top View
Dimensions in inches
0.237
60X Ø.035 ±.003 THRU
AFTER PLATING
2X Ø.166 +.003/-.000 THRU
AFTER PLATING
Accelnet Mounting Hardware:
qty Description
1 Socket Strip
1 Socket Strip
notes
1. P1 signals must be connected for current-sharing.
2. To determine copper width and thickness for P1 signals refer to specification IPC-2221.
(Association Connecting Electronic Industries, http://www.ipc.org)
3. Standoffs should be connected to etches on pc board that connect to frame ground for maximum noise suppression and immunity.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Bantam R30
1.140
2 1
J1
0.0787
(TYP)
0.0787
(TYP)
Mfgr Part number
Samtec SQW-112-01-L-D
Samtec Sqw-118-01-l-D
.000
0.591
2 1
P1
0.0787
(TYP)
Remarks
J1
P1
Tel: 781-828-8090
R30
note 1
2
0.199
.000
1.538
36 35
Fax: 781-828-6547
Page 9 of 18
RoHS
1
MOT U
MOT V
MOT W
Pgnd
+HV
