Jumper functions
The functions shown in the tables below are in effect when the jumper is in place.
When a jumper is removed, the stated function is disabled.
J5 connects to an external controller
Jp1
JP1 Remarks
A Shorts 150k balance scaler
Ref(-) input is grounded
B
Ref(+) input is grounded
C
Connects J5-3 to Amp: Balance
D
E R1 controls Amp: Balance
Jp2
JP2 Remarks
A Gain Select to Sgnd
B Amp: [Aok] drives DS1
C Amp: [oUT1] drives DS2
D Amp: [oUT2] drives DS3
E Connects J5-4 to Amp: /NegEnab
Jp3
JP3 Remarks
A Connects Sw2 to Amp: /negEnab
B Connects Sw1 to Amp: /Enable
C Connects Sw3 to Amp: /PosEnab
D Connects J5-5 to Amp: /Enable
E Connects J5-17 to Amp: /PosEnab
Jp4
JP4 Remarks
Connects J5-9 to Amp: I2T Time
A
Connects J5-21 to Amp: Current Peak Limit
B
C no connections
Connects J5-7 to Amp: Current Cont Limit
D
E Connects J5-18 to Amp: Gain Select
