Ruggedized digital servo drive for brushless/brush motors
Table of Contents

Advertisement

MASTER oRDERIng gUIDE
R42-090-06
Accelnet R42 servo drive, 3/6 A, 90 Vdc
R42-090-14
Accelnet R42 servo drive, 7/14 A, 90 Vdc
R42-090-30
Accelnet R42 servo drive, 15/30 A, 90 Vdc
APk-090-01
Development kit for R42 servo drive
ACCESSoRIES
QTY DESCRIPTIon
1
Connector kit
1
for Develop-
1
ment kit
1
APk-Ck-01
2
1
CAnopen
network kit
1
APk-nk
1
1
Heatsink kit
1
R42-Hk
4
APk-CV
APk-nC-10
APk-nC-01
APk-nT
CME 2
SER-Ck
DIMEnSIonS
Dimensions: mm [in]
58.2
[2.29]
26.8 ±0.25
[1.06 ±.010]
43.7
[1.72]
Note: Specifications subject to change without notice
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Accelnet
Connector, Euro, 5 Terminal, 5.08 mm
Connector, Euro, 4 Terminal, 5.08 mm
26 Pin Connector, High Density, D-Sub, Male, Solder Cup
26 Pin Connector, High Density, D-Sub, Female, Solder Cup
26 Pin Connector backshell
Adapter Assy, DB9 Female to RJ45 Jack (APK-CV)
CANopen Network Cable, 10 ft. (APK-NC-10)
CANopen Network Terminator (APK-NT)
Heatsink for R42
Heatsink Thermal Material
Heatsink Hardware
Adapter Assembly, DB9 Female to RJ45 Jack
CAnopen network Cable, 10 ft
CAnopen network cable, 1 ft
CAnopen network Terminator
CME 2 Drive Configuration Software on CD-ROM
Serial Cable kit
76.3
[3.01]
Ruggedized digital seRvo dRive
R42
Plus
6.35
[0.25]
20.5 ±0.25
[0.81 ±.010]
16.9
[0.67]
Tel: 781-828-8090
foR BRushless/BRush MotoRs
Rev 3.04-fr
Fax: 781-828-6547
Page 26 of 26
RoHS
05/22/2015
