MASTER ORDERING GUIDE
R52-090-07 Stepnet R52 stepper drive, 5/7 A, 20~90 Vdc
R52-090-10 Stepnet R52 stepper drive, 10/10 A, 20~90 Vdc
SPK-090-01 Development Kit for R52 stepper drive
ACCESSORIES
QTY DESCRIPTION
1 Connector, Euro, 5 Terminal, 5.08 mm
Connector Kit
1 Connector, Euro, 4 Terminal, 5.08 mm
for Develop-
1 26 Pin Connector, High Density, D-Sub, Male, Solder Cup
ment Kit
2 26 Pin Connector, High Density, D-Sub, Female, Solder Cup
SPK-CK-01
1 26 Pin Connector Backshell
1 Adapter Assy, DB9 Female to RJ45 Jack (SPK-CV)
CANopen
Network Kit 1 CANopen Network Cable, 10 ft. (SPK-NC-10)
SPK-NK
1 CANopen Network Terminator (SPK-NT)
1 Heatsink for R52
Heatsink Kit
1 Heatsink Thermal Pad
R52-HK
2 Screws, #4/40 x 1.25", SEMS
SPK-CV Adapter Assembly, DB9 Female to RJ45 Jack
SPK-NC-10 CANopen Network Cable, 10 ft
SPK-NC-10 CANopen network cable, 1 ft
SPK-NC-10 CANopen Network Terminator
CME 2 CME 2 Drive Configuration Software on CD-ROM
SER-CK Serial Cable Kit for Development Kit
DIMENSIONS
DIMENSIONS ARE MM [IN]
26.8 ±0.25
43.7 [1.06 ±.010]
[1.72]
Note: Specifications subject to change without notice
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Stepnet
58.2
[2.29]
76.3
[3.01]
R52
Plus
6.35
[0.25]
20.5 ±0.25
[0.81 ±.010]
16.9
[0.67]
Tel: 781-828-8090
RUGGEDIZED DIGITAL
STEPPER DRIVE MODULE
RoHS
Rev 1.01_tu
05/21/2013
Fax: 781-828-6547
Page 24 of 24
