Accelnet R22
ORDERING GUIDE
PART NUMBER DESCRIPTION
R22-055-18 R22 servo drive 6/18 Adc @ 55 Vdc
R22-090-09 R22 servo drive 3/9 Adc @ 90 Vdc
R22-090-24 R22 servo drive 12/24 Adc @ 90 Vdc
R22-090-60 R22 servo drive 30/60 Adc @ 90 Vdc
R22-180-09 R22 servo drive 3/9 Adc @ 180 Vdc
R22-180-18 R22 servo drive 6/18 Adc @ 180 Vdc
R22-180-20 R22 servo drive 10/20 Adc @ 180 Vdc
MDK-180-01* Development Kit for -09, -18-, -20, & -24 models
RDK-090-01 Development Kit for -50 & -60 models
MDK-CK Development Kit Connector Kit for MDK-180-01
RDK-CK Development Kit Connector Kit for RDK-090-01
R22-HL R22 Heatsink Kit, Low profile
R22-HS R22 Heatsink Kit, Standard
CME2 CME 2 Drive Configuration Software CD-ROM
SER-CK Serial Cable Kit for Development Kit
Add -R to part number for resolver option
* The R22 drives are RoHS.
The MDK-180-01 Development Kit is not RoHS

ORDERING INSTRUCTIONS

Example: Order 1 R22-090-09 drive with
Standard Heatsink, Development Kit,
and Development Kit Connector Kit
Qty Item Remarks
1 R22-090-09 Accelnet R22 servodrive
1 R22-HS Standard Heatsink
1 MDK-180-01 Accelnet R22 Development Kit
1 MDK-CK Connector Kit for Development Kit
1 CME2 CME2™ CD
1 SER-CK Serial Cable Kit
Notes
1. Heatsink kits are ordered separately and installed by
the customer, not at the factory.
