MASTER ORDERING GUIDE
R11-230-02 Xenus R11 Servo drive 1/2 Adc
R11-230-06 Xenus R11 Servo drive 3/6 Adc
Xenus R11 Servo drive 5/10 Adc
R11-230-10
ACCESSORIES
QTY REF
1
1
1
1
Drive
Connector
1
Kit
R11-CK 1
66 J4,J5,J6 Contact, female, for AWG 24~20 wire
8
2 J1,J2
1
CANopen
Connector
1
Kit
R11-NK 1
R11-NA-10
R11-NC-10
R11-NC-01
R11-NT
SER-CK
R11-CV
CME 2
Heatsink Kit
R11-HK
A/R

ORDERING EXAMPLE

Example: Order 1 R11-230-06 drive with resolver feedback, heatsink, and associated components:
Qty Item
1 R11-230-06-R
1 R11-CK
1 R11-HK
1 SER-CK
1 CME2
Note: Specifications subject to change without notice
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Xenus R11
DESCRIPTION
J1 Plug, 3 position, 5.0mm, female
J2 Plug, 4 position, 5.0 mm, female
J3 Connector housing, 6 position
J4 Connector housing, 10 position
J5 Connector housing, 30 position
J6 Connector housing, 20 position
J3 Contact, female, for AWG 24~20 wire
Wire insertion/extraction tool
D-Sub 9 position female to RJ-45 female (R11-CV)
RJ-45 plug to flying leads with crimps (R11-NA-10), 10 ft (3 m )
J1
CANopen terminator (R11-NT) (J1 plug with resistor)
J4 CANopen cable assembly: RJ-45 plug to flying leads with crimps, 10 ft (3 m )
J4 CANopen cable assembly: drive J4 plug to flying leads with crimps , 10 ft (3 m )
J4 CANopen cable assembly: drive J4 plug to flying leads with crimps , 1 ft (0.3 m )
J4 CANopen network teminator (J4 plug with resistor)
J7 Serial Cable Kit: D-Sub 9F to RJ-11 adapter + 6 ft (1.8 m) modular cable for drive J7
J4 Cable adapter: D-Sub 9F to RJ-45 female, for CAN cables
CME 2™ CD (CME 2)
1 Heatsink
1 Thermal Material
Hardware
Remarks
Xenus R11 servo drive with resolver feedback
Connector Kit
Heatsink kit
Serial Cable Kit
CME 2™ CD
RUGGEDIZED DIGITAL
SERVO DRIVE FOR
BRUSHLESS/BRUSH MOTORS
Add -S to model number for Sin/Cos version
Add -R to model number for Resolver version
Contact factory for RS-422 option
MANUFACTURER PART NO.
Wago: 51117974 or 721-103/026-047/RN01-0000
Wago: 51118008 or 721-104/026-047/RN01-0000
Molex: Micro-Fit 43025-0600
Samtec: Mini-Mate IPD1-05-D
Samtec: Mini-Mate IPD1-15-D
Samtec: Mini-Mate IPD1-10-D
Samtec: Mini-Mate CC79L-2024-01-F
Molex: Micro-Fit 43030-0008
Wago: 231-131
Tel: 781-828-8090
R11
RoHS
Rev 6.01_mo 03/19/2012
Fax: 781-828-6547
