Accelnet R23
DIMEnSIonS
DIMEnSIonS
.217 [5.51]
.217
[5.51]
1.166
[29.62]
See note 3
0.824
See note 3
[20.9]
noTES
1. Dimensions shown in inches (mm).
2. for R23-055-06 & R23-090-04: 0.394 [10.0],
3. for R23-055-06 & R23-090-04: 0.825 [21],
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: e-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
2.50 [63.5]
2.066 [52.48]
f or R23-055-10 & R23-090-08: 0.28 [7.1]
f or R23-055-10 & R23-090-08: 0.71 [18]
RUGGEDIZED DIGITAL
BRUSHLESS/BRUSH MOTORS
1.60
[40.64]
.281 [7.14]
Tel: 781-828-8090
R23
SERVO DRIVE fOR
.150
[3.81]
See note 2
.394 [10.0]
Fax: 781-828-6547
Page 13 of 24
RoHS
