Accelnet R20
MASTER ORDERING GUIDE
QUAD A/B MODELS SIN/COS MODELS
R20-055-18 R20-055-18-S
R20-090-09 R20-090-09-S
R20-090-18 R20-090-18-S
R20-090-36 R20-090-36-S
R20-180-09 R20-180-09-S
R20-180-18 R20-180-18-S
Contact factory for RS-422 option
ACCESSORIES
QTY
4
1
CONNECTOR KIT
1
R20-CK
1
1
1
CANOPEN
NETWORK KIT 1
R20-NK
1
1
HEATSINK KIT
1
R20-HK
4
R20-CV
R20-NC-10
R20-NC-01
R20-NT
CME 2
SER-CK

ORDERING EXAMPLE

Example: Order an R20-090-18-S servo drive with heatsink installed at factory and associated components:
Qty Item
1 R20-090-18-S-H
1 R20-CK
1 SER-CK
1 CME2
Note: Specifications subject to change without notice
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
RESOLVER MODELS
R20-055-18-R
R20-090-09-R
R20-090-18-R
R20-090-36-R
R20-180-09-R
R20-180-18-R
DESCRIPTION
Connector, 6 Terminal, 5.08 mm
26 Pin Connector, High Density, D-Sub, Solder Cup
26 Pin Connector Backshell
15 Pin Connector, High Density, D-Sub, Solder Cup
15 Pin Connector Backshell
Adapter Assy, DB9 Female to RJ45 Jack (XTL-CV)
CANopen Network Cable, 10 ft. (XTL-NC-10)
CANopen Network Terminator (XTL-NT)
Heatsink, Low Profile
Heatsink Thermal Material
Heatsink Hardware
Adapter Assembly, DB9 Female to RJ45 Jack
CANopen Network Cable, 10 ft
CANopen network cable, 1 ft
CANopen Network Terminator
CME 2 Drive Configuration Software on CD-ROM
Serial Cable Kit
Remarks
Accelnet R20 servo drive
Connector Kit
Serial Cable Kit
CME 2™ CD
RUGGEDIZED DIGITAL
SERVO DRIVE FOR
BRUSHLESS/BRUSH MOTORS
DESCRIPTION
Accelnet R20 R20 Servo drive, 55 Vdc, 6/18 A
Accelnet R20 R20 Servo drive, 90 Vdc 3/9 A
Accelnet R20 R20 Servo drive, 90 Vdc, 6/18 A
Accelnet R20 R20 Servo drive, 90 Vdc, 12/36 A
Accelnet R20 Servo drive, 180 Vdc, 3/9 A
Accelnet R20 Servo drive, 180 Vdc, 6/18 A
