When Changes Take Effect

N7000 RLP Parameters

LP Type
Line Interface Card 1
Line Interface Card 2
Configuring LPs and LAN Cards
When you add a new LP record, the change will be written to the database as soon as
you enter the final parameter value. When you modify an existing record, the change
will be written to the database immediately.
The change will become effective at the LP in one of the following ways:
A change to an RLP in an ICP, INM, or NMP node is immediately effective
when the database record is changed.
A change to LP 0–3 in a DPPM node, can be implemented by performing a
Configuration Update
taining the LP.
Be sure to perform the update to a DPPM node before the node
undergoes a re-IPL.
A change to LP 4–7 in a DPPM node will take effect at the next IPL of the node
containing the LP.
Parameter
LP Type
Line Interface Card 1,2
Although pressing [?] for help displays a range of
= AST Card
3 4
contains physical ports 0–3 for the RLP:
= not installed
0
= RS-232 (supports RS-232C/V.28 through I/O box and cable)
1
= RS-422 (supports RS-449/V.36, RS-530, or X.21 through I/O box and cable)
2
= V.35
3
contains physical ports 4–7 of the LP. The choices are the same as for Line Interface
Card 1.
( from the Main Menu) to the node con-
[B], [B], [D], [A]
Table 6-2 N7000 RLP Parameters
Valid Values
6
0–3
= T1/E1 = RLP-7000 Node
6
Default Value
6
1 ( RS-232
1–6 , these are the supported types:
)
6-7
