When Changes Take Effect at the Port

Frame Relay Port Parameters

Physical Interface
Configuring Frame Relay
When you add a new Port record, it will be written to the database as soon as you enter
the final parameter value. When you modify a parameter in an existing record, the
change will be written to the database immediately.
The change will become effective at the port in one of the following ways:
Press [F7] while still in Maintenance operations on the record. This will tempo-
rarily disable the port, then write the change to the software running in the node.
Re-IPL the node containing the changed port.
Parameter
Por t Type
Physical Interface
Blocked Port Flag
Line Speed Code
Maximum Frame Size
Logical DCE
Generate Clock
Rcv Clock (TT) from DTE
Mask Link Alarms
Link Management
N1 Polling Count
N2 Error Threshold
Monitored Events Count
Link Integrity Timer
(sec)
Poll Ver ification Timer
Enable Outgoing Rate Ctrl?
Enable Bandwidth Alloc?
128, 256, 512, 1024, 2048,
1
not configure a size greater than
headers can make the frame too large.
will simply be split, then re-assembled at the destination.
is the hardware interface, determined by the associated Line Interface Card (LIC) and
the cable attached to the port's I/O box connector. The LP record identifies the LIC,
and only the valid interfaces will be displayed as choices in the Port record. LICs are
shown in parentheses:
3 = RS-232 (RS-232)
= RS-449 (RS-422)
6
Table 8-2 Frame Relay Port Parameters
Valid Values
7
(frame relay)
3–8
Y/N
3–85
128–4096
Y/N
Y/N
Y/N
Y/N
0–2
1–255
1–10
1–10
5–30
5–30
(sec)
Y/N
Y/N
4096. If X.25 logical ports will be configured on this port, do
2048 4096
. If
2048
will not cause a problem, since larger frames
4 = V.25Bis_Dial (RS-232)
= RS-530 (RS-422)
7
Default Value
(not valid here)
3
N
10
1
1600
Y
N
N
N
0
6
2 if LMI
3
if Annex-D
4
10
15
N
N
is specified, additional X.25 and frame
5 = V.35 (V.35)
= X.21 (RS-422)
8
8-5
