Icons
Pull-down Menus
[F1] – View
19-12
Symbols used to represent components in network/subnetwork displays are shown
below:
FRX 8000
FRX 8000 with
attached NMP
N7400 DPPM
The circle on the current database master INM/NMP will be displayed as
hollow, rather than filled in as shown above.
Most selections across the top of a screen have associated pull-down menus that
appear when the selections are chosen (one exception is
page 19-13). When a pull-down menu appears, the default selection appears in white
text on a black background. Other items are in black text on a white background,
unless they are not valid at the current level, in which case they appear in light grey
text on a white background. The default value can be selected by pressing
by pressing the key (the one you pressed to display the menu) a second time.
[F"n"]
Each pull-down menu has an entry–
and allows you to make another
(default, except at port level, where it is not valid) allows you to
Zoom In
look at the next lower level of the network. (Position the cursor on
a component and select
(default at port level) returns you to the next higher level of the
Zoom Out
display. (Not valid at network level.)
Goto allows you to view another subnetwork, node, or LP without
moving one step at a time through the menus. When prompted,
enter the subnet/node/LP number(s). (Not valid at port level.)
Edit opens (only if your node is database master) Network Representation
operations (see Chapter 4), allowing you to make changes to
components of the network representation. (Not valid at node or port
level.)
FRX 8000 or N7500 ICP/INM
N7400 with
attached NMP
N7500 DPPM
Figure 19-9 Status Display Icons
Cancel . Selecting
selection; pressing
[F"n"]
Zoom In
N7500 with
attached NMP
Events , discussed on
Cancel exits the current menu
will do the same thing.
[Esc]
.)
FRX8000 3.0 User Guide, Rev 02
Subnetwork
, or
[Enter]
