- Page 1 Frame Relay Module for the SmartSwitch 9000 Installation & Setup Guide T he Co mp le te Ne tw orkin g S olution...
-
Page 2: About This Manual
Related Documents Copies of the Frame Relay Module Us er Guide and other Cabletron documents can be ordered from Cabletron Systems or your local distributor of Cabletron products. This typeface represents keyboar d input and video... - Page 3 LAN interface, located either on an interface module in the Smart- Switch 9000 or external to the rack. If the FRM will connect to an interface module in the SmartSwitch 9000, install the FRM into the nearest available slot.
- Page 4 1 and 2 are upside-down from RLP 1. The FRM is shipped with a pair of mounting rails that will hold the I/O boxes. Mount the rails to the cabinet frame, and mount the I/O boxes to the rails, using the hardware included with the assemblies.
-
Page 5: Checking For Proper Operation
1. Plug one end of each RLP cable (91-460-201) into an RLP connector on the FRM. Connect the other end of the RLP cable into a 60 Pin I/O box connector, as shown in Figure 3. (The ports are labeled on the I/O boxes.) Tighten the retaining screws. - Page 6 If you want to display the BOOTRPT.TXT file, press Main Menu. This completes the installation. If this FRM is the first one in a network that contains other FRMs running an older release of the software, the new software can be downloaded to the other FRMs.
- Page 7 Questions? If you have questions or problems, please contact Cabletron Systems Technical Support at: Phone: 603-332-9400 Fax: 603-337-3075 E-mail: support@ctron.com Ins tallation & Setup Guide T he Co mp le te Ne tw orkin g S olution Document number 09-48-06-001-01...
