Async Pad Profile Record - Cabletron Systems Netlink FRX8000 User Manual

When Changes Take Effect
Configuring Async Pads
A sync PA D Profile Maintenance
* Profile Name
A U sage (text)
B 1 PA D Recall Ch aracter
C 2 Ech o
D 3 Forwarding Ch aracters
E 4 Idle D elay (1/20 sec)
F 5 Device C ontrol
G 6 PA D Service Signals
H 7 Break Signal Operation
I 8 Discard Outp ut
J 9 Pad after CR
K 10 Line Folding
L 12 Flow C ontrol
1 Parameters 13-22
S elect:
Figure 13-1 Async PAD Profile Record
The numbers preceding the parameter names correspond to the
Recommendation.
Parameter 11, Speed, is not displayed because the value is determined by
the parameter
PAD ports, and is not configurable in the Profile record. (If
specified for
device connected to the port.
Press at the first screen to display the second screen. (The parameters are listed in
[1]
Table 13-1.)
When you add a new profile record in database maintenance operations, the change
will be written to the database as soon as you enter the final parameter value. When
you change a parameter in an existing record, the change will be written to the
database immediately.
The change will become effective to an async subscriber with the profile in its Port
and/or Subscriber record in one of the following ways:
Exit the profile record, open the Port record, and press
port, writes the change to the LP software in the node, then re-enable the port.
Perform an on-line update of the profile (
described under "Changing a Profile On
When the async subscriber logs out, the profile will be reloaded from the
database the next time he logs in.
When a call from the async subscriber is cleared, the profile will be reloaded
from the database the next time a call is placed.
S TD90
S imp le s tandard profile
1
Y
126
0
1
1
2
N
0
0
Y
in the Port Configuration records for async
X.3 Line Speed
in a Port record, the speed is that of the async
X.3 Line Speed
Line" on page 13-8).
from Main Menu
[A],[A],[C],[C]
. This will disable the
[F7]
from the Main Menu—
[B],[A],[J]
CCITT X.3
is
Autobaud
13-3
