Graphics-level Status Displays

19-10
Although Chapter 20
both status and statistics information. That statistics information is
included in this chapter.
This feature takes a Network Representation record (see Chapter 4) and displays a
screen similar to Figure 19-8. In Status Display operations, you can monitor status at
network, node, LP, or port level, as well as edit the record and perform some on-line
operations.
This Display is accessible only on a local VGA monitor.
Press at the Main Menu. The screen will go blank for a few seconds while the
[H]
software enters graphics level. When prompted, enter a network/subnetwork ID,
. (There must be an existing record in the database with this ID.)
1–250
F1 View
Figure 19-8 Network/Subnet Status Display
shows the number of unacknowledged events for all nodes that
Events:
report to the local node/NMP (See "
also appears in the upper right, a call has been placed to the local
Waiting
node/NMP, but has not yet been accepted.
A status display screen is automatically updated every five seconds, unless a pull-
down menu is displayed, in which case updates are recorded in the software but the
display is "frozen" until the menu is exited.
Connecting lines between components are shown in white if the link is up, or black if
it is down. Objects are color-coded, as shown in
reachable, and whether there are any outstanding events.
covers statistics, some graphics-level screens include
F2 Events F3 Environs F4 Operation s
S ubn et 1: Datan et 1
12
10
13
21
30
40
[F2] – Events
Table
Events:24
Call Waiting
11
20
[H]
from Main Menu
" on page 19-13.) If
19-1, to show whether they are
FRX8000 3.0 User Guide, Rev 02
Call
